Description
Specs & Details
|
CAPACITY |
|
| Total Capacity (cubic feet) |
6.8 cu ft
|
| Capacity (Cu. Ft.) |
2.5 Upper / 4.3 Lower
|
|
FILTER |
|
| App Filter – Cabinet Width |
Cooking 30 in. (Standard)
|
| App Filter – Control Type |
Electronic touchpad
|
| App Filter – Product Type |
Ranges Free-Standing Double Oven
|
| App Filter – Fuel Type |
Gas
|
| App Filter – Cooking Technology |
Convection
Traditional |
| App Filter – Convection |
Yes
|
| App Filter – Edge-to-Edge Cooktop |
Yes
|
| App Filter – Cooktop Type |
Continuous Grates with Griddle
|
|
APPEARANCE |
|
| Cooktop Burner Grate Color |
Matte Black
|
| Oven Door Features |
Big View Oven Window
|
| Handle Design |
Designer Style
|
| Handle Color |
Stainless Steel
|
| Control Knobs |
Stainless Steel Appearance
Weighted |
| Color Appearance |
Stainless Steel
|
|
POWER / RATINGS |
|
| Top Burner BTU Rating – Nat. Gas (000’s BTU’s) |
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 10.0
|
| Electrical Requirements |
120V
|
| Volts/Hertz/Amps |
120v; 60Hz; 15A
|
| Top Burner BTU Rating – LP (000’s BTU’s) |
(1) 15.0; (1) 12.0; (1) 9.5; (1) 5.0; (1) 8.0
|
| Bake/Broiler BTU Rating – Nat. Gas (000’s BTU’s) |
7.0 / 120V Bake Assist Element (Upper); 16.5 / 14.0 (Lower)
|
| Bake/Broiler BTU Rating – LP (000’s BTU’s) |
7.0 / 120V Bake Assist Element (Upper); 13.5 / 13.5 (Lower)
|
| Hertz | 60 |
|
WARRANTY |
|
| Parts Warranty |
Limited 1-year entire appliance
|
| Labor Warranty |
Limited 1-year entire appliance
|
| Warranty Notes |
See written warranty for full details
|
|
ACCESSORIES |
|
| Air Fry Basket |
Optional- JXAFTRAY1VSS
|
| Center Grate |
Optional – JXGRATE1
|
| Griddle Accessory |
Integrated Griddle (Included)
|
| LP Conversion Kit |
Included
|
|
WEIGHTS & DIMENSIONS |
|
| Net Weight |
205 lb
|
| Depth Without Handle |
26.75 in
|
| Height to Cooking Surface (in.) |
36 – 36.5
|
| Cabinet Width |
30 in
|
| Approximate Shipping Weight |
225 lb
|
| Overall Width |
30 in
|
| Overall Height |
47.25 in
|
| Overall Depth |
29.25 in
|
| Depth with Door Open |
43.5 in
|
| Oven Interior Dimensions (W x H x D) (in.) |
24 x 9-1/2 x 19-1/8 – Upper; 24 x 15 x 20-5/8 – Lower
|
|
FEATURES |
|
| Cooking System |
True Convection
|
| Ignition System |
Electronic
|
| Burner – Right Rear |
12,000 BTU
|
| Oven Control Features |
Audible Preheat Signal
Control Lock Capability Sabbath Mode |
| Oven Rack Features |
3 Oven Racks
|
| Burner – Left Rear |
5,000 BTU Precise Simmer
|
| Oven Cleaning Type |
Steam Clean
|
| Griddle |
Integrated (Included)
|
| Product Type |
Free-Standing Double Oven
|
| Cooktop Type |
Continuous Grates with Griddle
|
| Cooktop Burner Grate Material |
Heavy Cast Iron
|
| Fuel Type |
Natural Gas
|
| Burner – Center |
10,000 BTU Oval
|
| Interior Oven Light |
1 Auto Incandescent (Both Ovens)
|
| Control Location |
Front
|
| Cooktop Burner Grate Features |
Dishwasher Safe
|
| Control Type |
Electronic Touch
|
| Burner – Left Front |
15,000 BTU
|
| Sabbath Mode |
Yes
|
| Cooking Technology |
Traditional Upper; True Convection Lower
|
| Configuration |
Double Oven Range
|
| OU Certified |
No
|
| Oven Cooking Modes |
Convection Bake
Convection Roast No Preheat Air Fry |
| Cooktop Burner Type |
Sealed
|
| Burner – Right Front |
9,500 BTU
|
| Cooktop Surface |
Edge-to-Edge
Gray One-Piece Upswept Porcelain-Enamel |
| Oven Rack Positions (Single or Upper/Lower) |
2 / 5
|
